Fusion Splicer

Product Details:

Product Specification

Product Details:

Product SpecificationBrand FujikaraModel No. 80SReturn Loss Less than 60 dBTension Test 1.96 to 2.25 NDimensions 146WX159DX150H (mm) excluding rubber footFiber View And Magnification X / Y (320X magnification), or both X and Y simultaneously (200X magnification)View Display Two CMOS cameras and 4.73inch color LCD monitorTerminals USB 2.0(Mini-B) connector for PC communication. 6-pin Mini-DIN connector for HJS power supplyWeight 2.5kg with AC adaptor ADC-18, 2.7kg with battery BTR-09Electrode life 3000 arc-dischargesNumber Of Splice Cycle With Battery Typical 200 cycles (splice / tube heat) with BTR-09Applicable Protection Sleeve 60mm, 40mm and Fujikura FPS01 seriesSplicing Time Typical 7s with SM FAST, 10s with SM AUTO and 15s with AUTO modes with standard SM(ITU-T G.652)Splicing Mode Total 100 modesTube Heating Time Built-in tube heater with 30 heating modes / Typical 14s with Fujikura FP-03Storage Of Splice Result Splice data-2000, Image data-100Operating Condition 0 to 5,000m above sea level, 0 to 95%RH and -10 to 50 Degree C and up to 15m/s wind velocityStorage Condition 0 to 95%RH and -40 to 80 Deg C respectively. Battery -20 to 30 Deg C for long term
